There is no single “standard” size for LED film screens — instead, they are customizable and modular, allowing them to fit various glass surfaces or project needs. However, manufacturers follow certain common module sizes and pixel pitches, which help define the final display dimensions and resolution.
Here’s a breakdown to help you understand what’s typical:
Standard LED Film Screen Module Sizes
The transparent LED film screens come in flexible sheet modules that can be cut or connected to match the size of a glass panel.
| Standard Size (W × H) |
|---|
| 500mm × 240mm (≈19.7" × 9.4") |
| 480mm × 320mm (≈18.9" × 12.6") |
| 960mm × 320mm (≈37.8" × 12.6") |
| 1000mm × 400mm (≈39.4" × 15.7") |
| 1400mm × 400mm (≈55.1" × 15.8") |
Pixel Pitch and Viewing Distance
The pixel pitch determines how large your LED film screen should be for clear visuals.
| Pixel Pitch | Recommended Viewing Distance |
|---|---|
| P5 | 3–5 meters |
| P6 | 3–6 meters |
| P8 | 5–8 meters |
| P10 | 8–10 meters |
| P15 | 10–15 meters |
| P20 | 15–20 meters |
Screen Size Example Calculations
Because LED film screens are modular, the total screen size is created by connecting multiple panels:
-
For example:
- A 3 m × 2 m LED film wall using 480 × 320 mm modules would require ~6 panels across × 6 panels high = 36 panels.
- This allows seamless customization to any glass dimension.
In Summary
- There is no fixed “standard size”, only standard module dimensions (e.g., 480×320 mm).
- You can combine modules to create screens of any width or height.
- Choose the pixel pitch (P5–P20) according to viewing distance and transparency needs.
